Brass Mold Casting Low Pressure Die Casting Machine For Bathroom Accessories

Brand Name:	DZ
Model Number:	RD-5040-S
MOQ:	1 set
Price:	Negotiable
Packaging Details:	wood
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE ISO

Hydraulic Fluid Temperature:

Max. Die Opening Stroke:

370mm

Max. Die Weight:

200Kg

Total Weight:

Total Power:

125KW

Cooling System Water PH Value:

7~8.5

Cooling System Pressure:

3-5bar

Max. Die Ejector Stroke:

Supply Ability:

3 sets per month

Highlight:

Brass Mold Die Casting Machine

Bathroom Accessories Casting Machine

Product Description

Low Pressure Die Casting Machine For Brass Mold Casting, Suitable For Bathroom Accessories.

Product Description:

Brass Mold Casting Low Pressure Die Casting Machine For Bathroom Accessories 0

Features:

In low pressure die casting process molten metal is filled directly from the holding or casting furnace into the dies and sand mould from below,with low turbulence and an absolutely controlled filled casting process.

Technical Parameters:

Technical Parameters	Details
Furnace Capacity	1800KG
Hydraulic Fluid Temperature	≤55℃
Max. Die Weight	200Kg
Equipment Size (LWH)	520050003600mm
Air Pressure Compressed Air Consumption	15m³/H
Gas Flow	0.225m³/h
Max. Die Ejector Stroke	48mm
Max. Die Dimension	600400240mm
Cooling System Pressure	3-5bar
Cooling System Water PH Value	7~8.5

Applications:

For brass for the casting of sanitary fittings,faucets,water meter or valve bodies.

Packing and Shipping:

Packaging and Shipping for Low Pressure Die Casting Machine:

The Low Pressure Die Casting Machine is carefully packed in wooden crates to ensure that no damage occurs during transportation.
The Low Pressure Die Casting Machine is shipped by truck or train to the customer’s designated location.
The Low Pressure Die Casting Machine can also be shipped by air or sea if required.
The customer will be notified of the exact shipping date and tracking number once the machine is shipped.

FAQ:

Q: What is the brand and model of the Low Pressure Die Casting Machine? A: The brand is DZ and the model is RD-5040-S.
Q: Where is the Low Pressure Die Casting Machine from? A: It is from China.
Q: Does the Low Pressure Die Casting Machine have any certifications? A: Yes, it has CE and ISO certifications.
Q: What are the applications of the Low Pressure Die Casting Machine? A: It is suitable for die casting of various metals, including aluminum, zinc, magnesium, etc.
Q: What is the maximum pressure of the Low Pressure Die Casting Machine? A: It is 40 tons.
