Low Pressure Die Casting Machine
>
Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting
Detail Information
Place of Origin:
CHINA
Certification:
CE ISO
Max. Die Dimension:
600*400*240mm
Max. Die Opening Stroke:
370mm
Cooling System Pressure:
3-5bar
Furnace Inductors:
3*35KW
Equipment Size:L*W*H:
5200*5000*3600mm
Max. Die Weight:
200Kg
Max. Die Thickness:
2*120mm
Hydraulic Fluid Temperature:
≤55℃
Delivery Time:
20 work days
Supply Ability:
3 sets per month
Highlight:

125KW Auto Part Casting Machine

,

Brass Faucet Casting Machine

Product Description

Product Description:

Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting 0Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting 1Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting 2Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting 3Low Pressure Die Casting Machine For Brass Faucet And Auto Part Casting 4

Features:

  • Product Name: Low Pressure Die Casting Machine
  • Max. Die Thickness: 2*120mm
  • Gas Pressure: 0.5bar
  • Total Power: 125KW
  • Voltage: 380V
  • Max. Force of Ejector: 500kg
  • Low Pressure Die Casting Process
  • Low Pressure Casting Machine Manufacturer


Technical Parameters:



Properties Parameters
Equipment Size:L*W*H 5200*5000*3600mm
Total Weight 13T
Total power 125KW
Voltage 380V
Max. Die Dimensions 600*400*240mm
Max. Die Thickness 2*120mm
Max. Die Opening stroke 370mm
Max.Die Weight 200Kg
Max. force of die closing 2400KG
Max. force of ejector 500KW
Max. die ejector stroke 48mm
Furnace Melting rate 350KG/H
Furnace Capacity 1800KG
Furnace Inductors 3*35KW
Hydraulic Motor Power 8.7KW
Hydraulic Rated Pressure 8Mpa
Hydraulic fluid temperature ≤52℃
Cooling system Water PH value 7~8.5
Cooling system Pressure 3-5bar
Cooling system Temp. 20±2℃
Cooling system Flow ≥400L/Min ≤600L/Min
Air pressure Compressed air pressure 0.5-0.6Mpa
Air pressure Compressed air consumption 15m³/H


Applications:

Manufacturing industry: Producing a wide range of mechanical parts and assemblies for machinery.



Electronics and electrical industry: Crafting well-conductive brass electrical components.



Construction and decoration: Creating decorative pieces, architectural components, and items requiring a brass aesthetic.



Automotive industry: Manufacturing automotive components such as engine parts, transmission elements, and more.



Packing and Shipping:

Packaging and Shipping for Low Pressure Die Casting Machine:

  • The Low Pressure Die Casting Machine is packaged in a wooden crate with foam cushioning for protection.
  • The Low Pressure Die Casting Machine is shipped via truck or train to the customer's facility.


FAQ:

Q: What is the brand name of the Low Pressure Die Casting Machine?
A: The brand name of the Low Pressure Die Casting Machine is DZ.
Q: What is the model number of the Low Pressure Die Casting Machine?
A: The model number of the Low Pressure Die Casting Machine is RD-5040-S.
Q: Where is the Low Pressure Die Casting Machine manufactured?
A: The Low Pressure Die Casting Machine is manufactured in China.
Q: Is the Low Pressure Die Casting Machine certified?
A: Yes, the Low Pressure Die Casting Machine is certified with CE ISO.
Q: What is the capacity of the Low Pressure Die Casting Machine?
A: The capacity of the Low Pressure Die Casting Machine depends on the specific model.
