High Efficiency Metal Low Pressure Die Casting Machine 125KW

Brand Name:	DZ
Model Number:	RD-5040-S
MOQ:	1 set
Price:	Negotiable
Packaging Details:	wood
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE ISO

Gas Flow:

0.225m³/h

Hydraulic Rated Pressure:

Max. Force Of Ejector:

500kg

Air Pressure Compressed Air Pressure:

0.5-0.6Mpa

Total Power:

125KW

Furnace Inductors:

3*35KW

Equipment Size:L*W*H:

5200*5000*3600mm

Gas Pressure:

0.5bar

Supply Ability:

3 sets per month

Highlight:

Die Casting Machine 125KW

CE Metal Die Casting Machine

Product Description

Product Description:

High Efficiency Metal Low Pressure Die Casting Machine 125KW 0

Features:

Product Name: Low Pressure Die Casting Machine
Total Weight: 13T
Total Power: 125KW
Air Pressure Compressed Air Consumption: 15m³/H
Max. Force of Ejector: 500kg
Gas Pressure: 0.5bar
Metal Dia Casting Machine
Low Pressure Casting Machine

Technical Parameters:

Properties	Parameters
Equipment Size:LWH	520050003600mm
Total Weight	13T
Total power	125KW
Voltage	380V
Max. Die Dimensions	600400240mm
Max. Die Thickness	2*120mm
Max. Die Opening stroke	370mm
Max.Die Weight	200Kg
Max. force of die closing	2400KG
Max. force of ejector	500KW
Max. die ejector stroke	48mm
Furnace Melting rate	350KG/H
Furnace Capacity	1800KG
Furnace Inductors	3*35KW
Hydraulic Motor Power	8.7KW
Hydraulic Rated Pressure	8Mpa
Hydraulic fluid temperature	≤52℃
Cooling system Water PH value	7~8.5
Cooling system Pressure	3-5bar
Cooling system Temp.	20±2℃
Cooling system Flow	≥400L/Min ≤600L/Min
Air pressure Compressed air pressure	0.5-0.6Mpa
Air pressure Compressed air consumption	15m³/H

Applications:

The DZ RD-5040-S Low Pressure Die Casting Machine is a great choice for those looking for a reliable, efficient and cost-effective metal die casting solution. This machine is certified with CE ISO and has a max die thickness of 2*120mm. It features 3*35KW furnace inductors, a furnace capacity of 1800KG and a voltage of 380V. The cooling system flow is ≥400L/min ≤600L/min. This machine is perfect for those who need a low pressure die casting process that is accurate and cost-effective.

Packing and Shipping:

Packaging and Shipping

Low Pressure Die Casting Machine will be packaged in wooden crates and shipped by sea, air, or land. The crates will be designed to protect the machine from moisture and mechanical damage during its journey to the customer.

The crates will be secured with metal bands, and all shipping documents will be included in the package. The customer will be able to track the shipping progress with the included documents.

FAQ:

Q: What is the brand name of Low Pressure Die Casting Machine?
A: The brand name of Low Pressure Die Casting Machine is DZ.
Q: What is the model number of Low Pressure Die Casting Machine?
A: The model number of Low Pressure Die Casting Machine is RD-5040-S.
Q: Where is Low Pressure Die Casting Machine made?
A: Low Pressure Die Casting Machine is made in China.
Q: Does Low Pressure Die Casting Machine have any certifications?
A: Yes, Low Pressure Die Casting Machine has CE and ISO certifications.
Q: What applications is Low Pressure Die Casting Machine suitable for?
A: Low Pressure Die Casting Machine is suitable for producing high precision aluminum die casting products.
