Automatic Low Pressure Die Casting Machine For Casting Metal Products

Brand Name:	DZ
Model Number:	RD-7050-S
MOQ:	1 set
Price:	Negotiable
Packaging Details:	wood
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE ISO

Air Pressure Compressed Air Pressure:

0.5-0.6Mpa

Gas Pressure:

0.5bar

Furnace Capacity:

1800KG

Air Pressure Compressed Air Consumption:

15m³/H

Total Weight:

Max. Force Of Die Closing:

2400kg

Max. Die Opening Stroke:

370mm

Max. Die Dimension:

600*400*240mm

Supply Ability:

1 set /per month

Highlight:

Automatic Metal Die Casting Machine

0.5bar Gas Pressure Casting Machine

Product Description

Product Description:

Low Pressure Die Casting Machine is designed to help manufacturing companies with their production needs. It is an automatic casting machine that specializes in producing metal dia castings with a low pressure die casting process.

Automatic Low Pressure Die Casting Machine For Casting Metal Products 0

Features:

Product Name: Low Pressure Die Casting Machine
Gas Pressure: 0.5bar
Cooling System Flow: ≥400L/Min ≤600L/Min
Max. Die Thickness: 2*120mm
Melting Rate: 350KG/H
Cooling System Water Temperature: 20±2℃
Keywords: Low Pressure Casting Machine, Automatic Casting Machine, Metal Dia Casting Machine

Technical Parameters:

Properties	Parameters
Equipment Size:LWH	520050003600mm
Total Weight	13T
Total power	125KW
Voltage	380V
Max. Die Dimensions	600400240mm
Max. Die Thickness	2*120mm
Max. Die Opening stroke	370mm
Max.Die Weight	200Kg
Max. force of die closing	2400KG
Max. force of ejector	500KW
Max. die ejector stroke	48mm
Furnace Melting rate	350KG/H
Furnace Capacity	1800KG
Furnace Inductors	3*35KW
Hydraulic Motor Power	8.7KW
Hydraulic Rated Pressure	8Mpa
Hydraulic fluid temperature	≤52℃
Cooling system Water PH value	7~8.5
Cooling system Pressure	3-5bar
Cooling system Temp.	20±2℃
Cooling system Flow	≥400L/Min ≤600L/Min
Air pressure Compressed air pressure	0.5-0.6Mpa
Air pressure Compressed air consumption	15m³/H

Applications:

Suitable for brass die casting.

Packing and Shipping:

Packaging and Shipping for Low Pressure Die Casting Machine:

The Low Pressure Die Casting Machine will be securely wrapped in a waterproof plastic bag to protect from any kind of damage during shipping.
The Low Pressure Die Casting Machine will be further enclosed in a strong cardboard box. This box will be secured with bubble wrap and/or foam to ensure no movement within.
The Low Pressure Die Casting Machine will be shipped via a reputable courier service, preferably with insurance and tracking.

FAQ:

Q1: What is the brand name and model of Low Pressure Die Casting Machine?

A1: The brand name of Low Pressure Die Casting Machine is DZ and model number is RD-7050-S.

Q2: Where is the Low Pressure Die Casting Machine manufactured?

A2: The Low Pressure Die Casting Machine is manufactured in CHINA.

Q3: Does the Low Pressure Die Casting Machine have any certifications?

A3: Yes, the Low Pressure Die Casting Machine is certified with CE and ISO.

Q4: What are the main features of Low Pressure Die Casting Machine?

A4: The main features of Low Pressure Die Casting Machine include high-precision die casting, high production efficiency, and energy-saving.

Q5: What is the maximum weight of the Low Pressure Die Casting Machine?

A5: The maximum weight of the Low Pressure Die Casting Machine is 70 tons.
