CNC Polishing Machine
>
Rotary 35KW Automatic Brass Tube CNC Polishing Machine No Need Dusting

Rotary 35KW Automatic Brass Tube CNC Polishing Machine No Need Dusting

Brand Name: DZ
Model Number: NC-64
MOQ: 1unit
Price: Negotiable
Packaging Details: wood
Payment Terms: L/C, T/T, Western Union
Detail Information
Place of Origin:
China(Mainland)
Certification:
CE ISO
Dimensions (L*W*H):
4400*3400*2900
Machine Power:
35KW
Rated Voltage:
380V
Max. Diameter Of Polishing Wheel:
600mm
Min. Diameter Of Polishing Wheel:
400mm
X-Axis Travel (mm):
1200
Y-Axis Travel (mm):
1100
Z-Axis Travel (mm:
700
U-Axis Travel (mm):
±90°
V-Axis Travel (mm):
±360°
W-Axis Travel (mm):
±360°
Supply Ability:
30 units/per month
Highlight:

Brass Tube CNC Polishing Machine

,

35KW Automatic Polishing Machine

,

Stainless Steel CNC Polishing Machine

Product Description

Rotary Automatic Polishing Machine Easy Operation No Need Edit Program No Need Dusting No Need Debug

Metals Brass Tube Fitting Grinding Polishing ROBOT Automatic Polishing Machine For Stainless Steel

Automatic Polishing Machine CNC 6 Axis Faucet Polishing Machine





Precision polishing.


-Uniform polishing quality without deformation of the processed parts.

-High production. Simultaneous polishing of two equal parts in each polishing cycle.

-Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

-Quick replacement of the fixtures.

-Quick replacement of the polishing mops.

-Cost-reduction in the amount of fixtures.

-Important reduction in mops and polishing compounds consumption.

-Polishing system avoiding excessive temperature of the parts during the working process.

-Quick and easy programming. Interactive Teach System.

-High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

TECHNICAL PARAMETERS

No Items Specifications
1 Dimensions (L*W*H) 3000*3100*2900mm
2 Machine Power 17KW
3 Rated Voltage 380V
4 Max. Diameter of polishing wheel 600mm
5 Min. Diameter of polishing wheel 400mm
6 X-Axis travel (mm) 1100
7 Y-Axis travel (mm) 900
8 Z-Axis travel (mm) 700
9 U-Axis travel (mm) ±60°
10 V-Axis travel (mm) ±360°
11 W-Axis travel (mm) ±360°
12 Max.speed X axis 20m/min
13 Max.speed Y axis 20m/min
14 Max.speed Z axis 20m/min
15 Max.speed U axis 30°/sec.
16 Max.speed V axis 30°/sec.
17 Max.speed W axis 30°/sec.
