Name: Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting
Brand: Xiamen DingZhu Intelligent Equipment Co.,Ltd
SKU: NC-64
Availability: InStock

Brand Name:	DZ
Model Number:	NC-64
MOQ:	1
Packaging Details:	wood
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE ISO

Highlight:

High Efficient CNC Polishing Machine

Automatic Brass Tube CNC Polishing Machine

Rotary Brass Tube CNC Polishing Machine

Product Description

Detail Information
Dimensions (LWH):	440034002900	Machine Power:	35KW
Rated Voltage:	380V	Max. Diameter Of Polishing Wheel:	600mm
Min. Diameter Of Polishing Wheel:	400mm	X-Axis Travel (mm):	1200
Y-Axis Travel (mm):	1100	Z-Axis Travel (mm:	700
U-Axis Travel (mm):	±90°	V-Axis Travel (mm):	±360°
W-Axis Travel (mm):	±360°
High Light:	Automatic Brass Tube CNC Polishing Machine,Rotary Automatic CNC Polishing Machine,35KW Rotary Automatic Polishing Machine

Product Description:

High Efficient Rotary Automatic Brass Tube CNC Polishing Machine No Need Dusting

Precision polishing.

- Uniform polishing quality without deformation of the processed parts.

- High production. Simultaneous polishing of two equal parts in each polishing cycle.

- Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

- Quick replacement of the fixtures.

- Quick replacement of the polishing mops.

- Cost-reduction in the amount of fixtures.

- Important reduction in mops and polishing compounds consumption.

- Polishing system avoiding excessive temperature of the parts during the working process.

- Quick and easy programming. Interactive Teach System.

- High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

TECHNICAL PARAMETERS

No	Items	Specifications
1	Dimensions (LWH)	300031002900mm
2	Machine Power	17KW
3	Rated Voltage	380V
4	Max. Diameter of polishing wheel	600mm
5	Min. Diameter of polishing wheel	400mm
6	X-Axis travel (mm)	1100
7	Y-Axis travel (mm)	900
8	Z-Axis travel (mm)	700
9	U-Axis travel (mm)	±60°
10	V-Axis travel (mm)	±360°
11	W-Axis travel (mm)	±360°
12	Max.speed X axis	20m/min
13	Max.speed Y axis	20m/min
14	Max.speed Z axis	20m/min
15	Max.speed U axis	30°/sec.
16	Max.speed V axis	30°/sec.
17	Max.speed W axis	30°/sec.

Packing and Shipping

Packaging and Shipping for Automatic Polishing Machine

The Automatic Polishing Machine is carefully packaged in a durable cardboard box to ensure it is delivered in perfect condition.

The box is then taped shut and labeled with the necessary shipping details, such as the shipping address, product weight, and dimensions.

Once the package is prepared, it is shipped via a reliable carrier, such as UPS or FedEx, to the destination.

Wheel Polishing Machine Max. Speed Of 30°/Sec. For V-Axis And W-Axis Four Stations Automatic Polishing Machine 3

FAQ

Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge

Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge

Q:How long the guarantee?
A: one year and charge for repair the whole life.

Q: How about the lead time and delivery time of my order?
A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
