Home ProductsCNC Polishing MachineAutomatic Grinding Wheel Polishing Machine for Faucet Door Handle
Automatic Grinding Wheel Polishing Machine for Faucet Door Handle
Automatic Grinding Wheel Polishing Machine for Faucet Door Handle
Automatic Grinding Wheel Polishing Machine for Faucet Door Handle Automatic Grinding Wheel Polishing Machine for Faucet Door Handle Automatic Grinding Wheel Polishing Machine for Faucet Door Handle Automatic Grinding Wheel Polishing Machine for Faucet Door Handle Automatic Grinding Wheel Polishing Machine for Faucet Door Handle

Automatic Grinding Wheel Polishing Machine for Faucet Door Handle

Product Details:
Place of Origin: China
Brand Name: DZ
Certification: CE
Model Number: HLD-50E
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: wood
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30sets / month
Contact Now

Detail Information
Weight: 4000KG Voltage: 380V/50Hz
Condition: 100%New After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Field Maintenance And Repair Service,Field Installation
Use: Machining, Deburring, Grinding, Polishing Type: Angle Polisher
Warranty: 1 Year Name: Grinding Robotic
Function: Machining, Deburring, Grinding, Polishing
High Light:

Automatic Grinding Wheel Polishing Machine

,

Faucet Grinding Polishing Machine

,

Automatic Door Handle CNC Polishing Machine

Product Description

Automatic Grinding Wheel Polishing Machine / Faucet / Door handle / Door lock panel / Golf head

I. Features

  • Robotic cell for Grinding Faucets
  • Typical products to process: Brass casted faucets, zamak levers, zamak faucets, shower heads and any sanitary ware
  • Compact cell, reduced space required for installation
  • Customizable Layout: Various robot brand Integration
  • Multiple applications possible: Machining, Deburring, Grinding Polishing, Satin
  • Customized HMI: Easy Adjustment
  • High Adaptability: Multiple part geometry processing
  • Calibration System: High Process Repeatability
  • Complex geometries processing
  • Up to 100% Surface Grinding Processing


II.CHARACTERISTIC



1.The automatic polishing machine is an exclusive polishing system consisting 4 manipulators with of 6 Axis rotary system; Multiple stations simultaneous operation ensures high flexibility and high product efficiency.



2.The control system adopts PROMAX motion control technology from Italy, with stable performance and high control accuracy.



3.Programming method: teaching programming ,with portable handed device, contains manually mode to simulate the workmanship polishing and record the track; automatically operating model is available with pre-set parameters program.



4.Polishing pressure and wear compensation control performance: When the polishing cloth wheel is worn out, the system can detect that the torque has become smaller and automatically the compensation in all directions.



5.Linear speed compensation: When the outer diameter of the cloth wheel is reduced, the system automatically increases the speed and compensation;



6.Program setting of add polishing wax:free setting of wax spraying time and frequency according to the characteristics of product.choice of slid compound or liquid compound.



7.Fully digital control, it can store 50 programs. Programs can be saved and recalled at any time.



8. CN/EN language display on Touch Panel. It is to set all parameters for an easy operation; fault codes display and alarm pages for quick troubles shooting and repair.





Working area 1800*2500mm
Feed height 200mm
Transmission X/Y rack and pinion, Z ball screw
Table structure T slot with clamp
Spindle power 4.5KW*2
Spindle speed 24000r/min
Travelling speed 25m/min
Working speed 20m/min
Working Delicacy 0.005mm
Repositioning Accuracy 0.05mm
Driving Motor Stepper
Control System DSP/Ncstudio Control System
Command Code G Code*.u00*.mmg*.plt
Power(without spindle) 1500W
Voltage AC380/50HZ
Running Environment Temperature:0 degree~45 degree
Software Artcam/Type3,other CAD/CAM

Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 0Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 1Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 2Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 3Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 4Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 5Automatic Grinding Wheel Polishing Machine for Faucet Door Handle 6

FAQ

Q1. Where is your factory located ? How can I visit it ?
A : Our factory is located in Quanzhou city,Fujian province,China. You can fly to Jinjiang or Xiamen air port, we will pick you up.


Q2. Are you produce polishing machine's specific parameters according to the samples?
A: Yes, we produce the machine you want by your samples or technical drawings. Usually one machine have different molds and fixtures like metal polishing machine,die casting machine.


Q3. What is your sample service?
A: We can supply the sample testing which client want to produce if we have ready machine in stock, but the customers have to pay the sample shipping cost.


Q4. What is your MOQ of your machine?
A: Normally our MOQ is 1 set.


Q5. Do you test all your machine before delivery?
A: Yes, we have 100% test before delivery.


Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
