CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets
CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets

CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets

Product Details:
Place of Origin: China
Brand Name: DZ
Certification: CE ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: wooden case packing
Delivery Time: 20days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20sets/per month
Contact Now

Detail Information
Voltage: 380V/50Hz Condition: 100%New
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Field Maintenance And Repair Service,Field Installation Use: Grinding And Polishing
Type: Metal Polishing Machine,Angle Polisher Application: Brass,Steel, Stainless Steel,Aluminum Parts
Warranty: 1 Year Name: Fully Automatic Metal Polishing Machine
High Light:

CNC System Robotic Polishing Machine

,

Grinding Faucets Robotic Polishing Machine

,

Copper Surface Robotic Polishing Machine

Product Description

CNC System Copper Surface Faucet Grinding Robot Industrial Polishing Machine Metal Spare Part Automatic Grinding Machine
Robotic Grinding Unit for Bathroom Fittings and Accessories


I. Features

Robotic cell for Grinding Faucets
Typical products to process: Brass casted faucets, zamak
levers, zamak faucets, shower heads and any sanitary ware
Compact cell, reduced space required for installation
Customizable Layout: Various robot brand Integration
Multiple applications possible: Machining, Deburring, Grinding
Polishing, Satin
Customized HMI: Easy Adjustment
High Adaptability: Multiple part geometry processing
Calibration System: High Process Repeatability
Complex geometries processing
Up to 100% Surface Grinding Processing


II. CHARACTERISTIC

3.1 FUNAC robotic M-20Ia/35M
3.2 Program modular, programming easiness with self-learning system.
3.3 Programming method:demonstrator programming ,with protable handed device, contains manually mode to simulate the workmanship grinding and record the track; automatically operating model is available with pre-settled parameters program.
3.4 Full digital control, the program can be saved and called at any time.
3.5 Rotary sand belt machine and multi - grade sandpaper grinding process can be completed at one time.
3.6 High precision, high efficiency.



III.System composition and main technical parameters


Code Item 20GA 20GB-II 20GB-III 35G-II 35G-III 50G-II 50G-III 　
1 Robot Cell FUNAC FUNAC FUNAC FUNAC FUNAC FUNAC FUNAC 　
2 Model 20iA/20 20iA/20 20iA/20 20iA/35 20iA/35 70iA/50 70iA/50 　
3 Voltage 380V 380V 380V 380V 380V 380V 380V 　
4 Power 10.5KW 10.5KW 15KW 10.5KW 15KW 1６KW 20.5KW 　
5 Sand Belt Machine Qty. 1 2 3 2 3 2 3 　
6 Sand Belt Qty. 4 4 6 4 6 4 6 　
7 Sand belt Dimensions 3000mm 3000mm 3000mm 4000mm 4000mm 4000mm 4000mm 　
8 Feed Table 1 1 1 1 1 1 1

　


CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 0CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 1CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 2CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 3CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 4CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 5CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 6CNC System Copper Surface Robotic Polishing Machine For Grinding Faucets 7
