| Brand Name: | DZ |
| Model Number: | NC-64 |
Automatic Metal Surface Finishing Machine CNC Buffing Polishing Machine
Description
The DX4040 is an economical engraving and milling machine of our company, mainly for graphite, copper electrode and aluminum alloy processing, shoe mold manufacturing, and watch industry.
The whole machine structure uses all the cast structure of iron, two annealings eliminate stress, and the machine tool reinforcement is scientific to ensure no deformation. Increase the width of the bottom of the box base, and the stability is good when cutting at high speed. DX4040 uses grinding ball screw C3 grade, Taiwan PMI/ HIWIN H-class rail, three-axis precision less than 0.015mm. With high processing precision, small size, low price, this machine is suitable for high precision machining of small parts.
Product Info
| No | Items | Specifications |
| 1 | Dimensions (L*W*H) | 3000*3100*2900mm |
| 2 | Machine Power | 17KW |
| 3 | Rated Voltage | 380V |
| 4 | Max. Diameter of polishing wheel | 600mm |
| 5 | Min. Diameter of polishing wheel | 400mm |
| 6 | X-Axis travel (mm) | 1100 |
| 7 | Y-Axis travel (mm) | 900 |
| 8 | Z-Axis travel (mm) | 700 |
| 9 | U-Axis travel (mm) | ±60° |
| 10 | V-Axis travel (mm) | ±360° |
| 11 | W-Axis travel (mm) | ±360° |
| 12 | Max.speed X axis | 20m/min |
| 13 | Max.speed Y axis | 20m/min |
| 14 | Max.speed Z axis | 20m/min |
| 15 | Max.speed U axis | 30°/sec. |
| 16 | Max.speed V axis | 30°/sec. |
| 17 | Max.speed W axis | 30°/sec. |
Feature
1.Welded lathe bed of profiled steel, stabilizing treated under high temperature
2.Y axis with double motors to drive that ensures stable and precise performance
3. With high precision rack gear transmission,with imported square linear guide rail,that ensure high accuracy,fast speed,heavy duty with long service life.
4. Professional design and high quality machine parts provides this machine with low break down rate
5. Unique double water cooling system ensured spindle cooling and cutter cooling with long working time.
6. Welded lathe bed of profiled steel, stabilizing treated under high temperature
7. All dust-proof design.
8. It not only can cut, engrave marble stones,but also can process wood foam plastics and soft metal.
Application
Marble, granite, China black, bluestone, jade, ceramic, crystal, glass, plastic, plexiglass, PVC board, bamboo, aluminum panels, metal etc. material.
Applicable industry
Stone, tombstone processing, advertising, decoration, crafts etc. 2D,3D carving, three-dimensional relief, cutting, drilling, industries.
|
|
