Product Details:
|
|
| Place of Origin: | China(Mainland) |
|---|---|
| Brand Name: | DZ |
| Model Number: | HZ-450 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1set |
| Price: | Negotiable |
| Packaging Details: | 1.Outsidepackage: Standard export wooden cases; 2.Inner package: Stretch film; Shipping: Container transport. |
| Delivery Time: | 2week |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30 Set/Sets per Month |
|
Detail Information |
|||
| Certification: | CE | Condition: | New |
|---|---|---|---|
| Product Name: | Die Casting Machine | Hydraulic Lube: | 165 L |
| Technology: | Gravity Die Casting Technology | Application Fields: | Hardware,valves,household Appliances,auto Parts Ect. |
| High Light: | brass die casting machine,copper die casting machine |
||
Product Description
Machines are suitable for producing plumbing fittings,hardware,sanitary ware,auto parts which gravity model casting with brass,zinc,aluminium,steel,iron ore and alloy,ferrous metal and non-ferrous metal.
(1) Circuits are all controlled by PLC,data setting adopts touch screen ,electrical components are
imported from Japan and hydraulic components are as well imported from outside.
(2) For gravity model casting with brass and ferroalloy.
(3)Front casting,lateral casting and secondary casting are optional.
(4) Individual cooling time of model is adjustable.
(5) The dismantling ,assembly and cleaning of model are convenient.
(6) Two functions of manual and automatic circulation are available.Totalizing counter and preset
counter are arranged to record the piece number of on duty production.
(7) Adjustment range of model is defined to make the using of different models easy and reduce
requirement of model's exterior physical dimension.
(8) This casting machine can store 100 sets model casting operation programs and you can set your
password.
| TECHNICAL PARAMETERS | ||
| 1 | MAX MOULD SIZE | 450mm |
| 2 | Max Mould Wieght | 130KG |
| 3 | Longest Merger Distance | ≤250mm |
| 4 | Hydraulic Pressure | 40-60KPa |
| 5 | Lateral Casting Angie | 0º-90º |
| 6 | Frantal Casting Angle | 0º-110º |
| 7 | Hydraulic Oil | 163L |
| 8 | Toal Power | 5.5KW |
| 9 | Instaling Top Care Device | 20mm travel |
| 10 | Net Weight | 1750KG |
| 11 | Size Of Appearance Of Machine | 2250*2160*1560mm |
Click the link to view video:
https://www.youtube.com/watch?v=wfANIO7Hw-w&list=UUMEJdKjNOuRhrF8Kyh8fX_A&index=14
