Product Details:
|
|
Place of Origin: | CHINA |
---|---|
Brand Name: | DZ |
Certification: | CE ISO |
Model Number: | NC64 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | wood |
Delivery Time: | 20 work days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 3 sets per month |
Detail Information |
|||
W-axis Travel: | ±720° | X-axis Max. Speed: | 20m/min |
---|---|---|---|
Z-axis Travel: | 700mm | V-axis Travel: | ±720° |
X-axis Travel: | 1000mm | Machine Power: | 35KW |
Y-axis Max. Speed: | 20m/min | Min. Diameter Of Polishing Wheel: | 400mm |
High Light: | Fast CNC Polishing Machine,1000mm X Axis Polishing Machine |
Product Description
Code | Item | Specifications |
1 | Dimensions (L*W*H) | 4400*3400*2900mm |
2 | Machine Power | 35KW |
3 | Rated Voltage | 380V 50Hz |
4 | Max. Diameter of polishing wheel | 600mm |
5 | Min. Diameter of polishing wheel | 400mm |
6 | X-Axis travel (mm) | 1000 |
7 | Y-Axis travel (mm) | 900 |
8 | Z-Axis travel (mm) | 700 |
9 | U-Axis travel (mm) | ±90° |
10 | V-Axis travel (mm) | ±360° |
11 | W-Axis travel (mm) | ±360° |
12 | Max.speed X axis | 20m/min |
13 | Max.speed Y axis | 20m/min |
14 | Max.speed Z axis | 20m/min |
15 | Max.speed U axis | 30°/sec. |
16 | Max.speed V axis | 30°/sec. |
17 | Max.speed W axis | 30°/sec. |
This machine is perfect for metal surface polishing, and it can offer a smooth and shiny finish to your products. With its advanced technology, the DZ NC64 CNC Polishing Machine is capable of achieving high accuracy and repeatability in the polishing process. It can be used to polish different kinds of metal surfaces, such as aluminum, copper, and stainless steel, and it also offers great flexibility with its variable speed settings and adjustable polishing wheel size. With its powerful performance and reliable operation, the DZ NC64 CNC Polishing Machine is the perfect choice for any metal surface polishing job.
CNC Polishing Machines are packaged with the following materials:
The CNC Polishing Machine is then shipped via a reliable freight service to the customer's address.
