Industry 380V Digital Copper Alloy Faucet Surface Polishing Machine Stainless Steel Door Handles Buffing Equipment
| Brand Name: | DZ |
| Model Number: | NC-64 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Packaging Details: | wood |
| Payment Terms: | L/C,T/T,Western Union |
Detail Information
Place of Origin:
China
Certification:
CE ISO
Dimensions (L*W*H):
4400*3400*2900
Machine Power:
35KW
Rated Voltage:
380V
Max. Diameter Of Polishing Wheel:
600mm
Min. Diameter Of Polishing Wheel:
400mm
Delivery Time:
20 week
Supply Ability:
30sets / month
Highlight:
Digital CNC Polishing Machine
,Door Handles CNC Polishing Machine
,CNC Copper Polishing Machine
Product Description
Industry 380V Digital Copper Alloy Faucet Surface Polishing Machine
Advanced stainless steel door handles buffing equipment designed for precision surface finishing in industrial applications.
Automatic Polishing Machine Characteristics
- 4 manipulators with 6-axis rotary systems for high flexibility and production efficiency
- Italian PROMAX motion control technology for stable performance and high accuracy
- Teaching programming with portable handheld device for manual simulation and automatic operation
- Automatic polishing pressure and wear compensation control
- Linear speed compensation for consistent polishing quality
- Programmable wax spraying system with choice of solid or liquid compound
- Fully digital control with capacity for 50 program storage
- Bilingual CN/EN touch panel display with fault code diagnostics
Four-Station Automatic Polishing Machine Advantages
- Precision polishing with uniform quality and no part deformation
- High production capacity with four simultaneous working stations
- Complete automation including waxing system
- Quick fixture and polishing mop replacement
- Reduced consumption of fixtures, mops, and polishing compounds
- Temperature-controlled polishing system
- Interactive teach programming for easy operation
- Multi-angle polishing capability in any position
- High profitability with single operator managing multiple machines
Technical Specifications
| Code | Item | Specifications |
|---|---|---|
| 1 | Dimensions (L*W*H) | 4400*3400*2900 |
| 2 | Machine Power | 35KW |
| 3 | Rated Voltage | 380V |
| 4 | Max. Diameter of polishing wheel | 600mm |
| 5 | Min. Diameter of polishing wheel | 400mm |
| 6 | X-Axis travel (mm) | 1100 |
| 7 | Y-Axis travel (mm) | 900 |
| 8 | Z-Axis travel (mm) | 700 |
| 9 | U-Axis travel (mm) | ±90° |
| 10 | V-Axis travel (mm) | ±360° |
| 11 | W-Axis travel (mm) | ±360° |
| 12 | Max.speed X axis | 20m/min |
| 13 | Max.speed Y axis | 20m/min |
| 14 | Max.speed Z axis | 20m/min |
| 15 | Max.speed U axis | 30°/sec. |
| 16 | Max.speed V axis | 30°/sec. |
| 17 | Max.speed W axis | 30°/sec. |
Product Gallery
Frequently Asked Questions
Can you arrange installation and commissioning?
Yes, we can arrange installation and commissioning at the buyer's expense.
Can you provide production education?
Yes, we can provide production education at the buyer's expense.
What is the warranty period?
One-year warranty with lifetime repair service available at charge.
What is the lead time and delivery schedule?
Large cargo delivery within 15-25 working days, depending on quantity, delivered as per agreed schedule.
