Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | DZ |
Certification: | CE ISO |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1set |
Packaging Details: | wooden case packing |
Delivery Time: | 20days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 20sets/per month |
Detail Information |
|||
Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Overseas Service Center Available |
---|---|---|---|
Certification: | ISO,CE | Weight: | 2000kg |
Color: | Customized | Voltage: | 220V / 380V / 415V |
Function: | Making Sand Core | Warranty: | 1 Year |
Sorting Accuracy: | ≥99.99% | ||
High Light: | CE Certification Sand Core Shooting Machine,Sanitary Ware Sand Core Shooter,Sanitary Ware Sand Core Shooting Machine |
Product Description
# | Item | Specification |
1 | Max. Weight of Sand Core | 8kg |
2 | Max. Size of Core Box ( L x W x H) | (450*330*220)mm |
3 | Heating Plate ( L x W) | (400*300)mm |
4 | Heating Power | 9.6kw |
5 | Downward Stroke of Ejection Head | ≤30mm |
6 | Stroke of Mold Opening | ≤300mm |
7 | Max. Stroke of Core Remove | 150mm |
8 | Conveyor ( L x W x H) | (2200*450*100)mm |
9 | Total Power | 13.2kw |
10 | Rising Angle of Conveyor | 2°~4° |
11 | Speed of Transportation | 72mm/s |
12 | Machine Size ( L x W x H) | (3500*1480*3400)mm |
13 | Speed of Lift (Single Time) | 35s |
14 | Weight of Lift ( Single Time) | 10kg |
15 | Total Weight | 2000kg |
16 |
Hydraulic pressure |
50Kg/cm² |
FAQ:
Q1. Where is your factory located? How can I visit it?
A: Our factory is located in Xiamen city, Fujian province, China.
Q2. Are you produce the machine’s specific parameters according to the samples?
A: Yes, we produce the sand core shooting machine you want by your samples or technical drawings. Usually, one machine has different molds and fixtures like a metal polishing machine, die casting machine.
Q3. What is your sample service?
A: We can supply the sample testing that which client wants to produce if we have a ready machine in stock, but the customers have to pay the sample shipping cost.
Q4. What is the MOQ of your machine?
A: Normally our MOQ is 1 set.
Q5. Do you test all your machine before delivery?
A: Yes, we have 100% test before delivery.
Q6: How do you make our business a long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
