|Place of Origin:||China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1set|
|Packaging Details:||wooden case packing|
|Payment Terms:||L/C, T/T, Western Union|
|Supply Ability:||20sets/per month|
|Condition:||New||After-sales Service Provided:||Engineers Available To Service Machinery Overseas,Overseas Service Center Available|
|Color:||Customized||Voltage:||220V / 380V / 415V|
|Function:||Making Sand Core||Warranty:||1 Year|
|1||Max. Weight of Sand Core||8kg|
|2||Max. Size of Core Box ( L x W x H)||(450*330*220)mm|
|3||Heating Plate ( L x W)||(400*300)mm|
|5||Downward Stroke of Ejection Head||≤30mm|
|6||Stroke of Mold Opening||≤300mm|
|7||Max. Stroke of Core Remove||150mm|
|8||Conveyor ( L x W x H)||(2200*450*100)mm|
|10||Rising Angle of Conveyor||2°~4°|
|11||Speed of Transportation||72mm/s|
|12||Machine Size ( L x W x H)||(3500*1480*3400)mm|
|13||Speed of Lift (Single Time)||35s|
|14||Weight of Lift ( Single Time)||10kg|
Q1. Where is your factory located? How can I visit it?
A: Our factory is located in Xiamen city, Fujian province, China.
Q2. Are you produce the machine’s specific parameters according to the samples?
A: Yes, we produce the sand core shooting machine you want by your samples or technical drawings. Usually, one machine has different molds and fixtures like a metal polishing machine, die casting machine.
Q3. What is your sample service?
A: We can supply the sample testing that which client wants to produce if we have a ready machine in stock, but the customers have to pay the sample shipping cost.
Q4. What is the MOQ of your machine?
A: Normally our MOQ is 1 set.
Q5. Do you test all your machine before delivery?
A: Yes, we have 100% test before delivery.
Q6: How do you make our business a long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
