Brand Name: | DZ |
MOQ: | 1set |
Packaging Details: | wooden case packing |
Payment Terms: | L/C, T/T, Western Union |
# | Item | Specification |
1 | Max. Weight of Sand Core | 8kg |
2 | Max. Size of Core Box ( L x W x H) | (450*330*220)mm |
3 | Heating Plate ( L x W) | (400*300)mm |
4 | Heating Power | 9.6kw |
5 | Downward Stroke of Ejection Head | ≤30mm |
6 | Stroke of Mold Opening | ≤300mm |
7 | Max. Stroke of Core Remove | 150mm |
8 | Conveyor ( L x W x H) | (2200*450*100)mm |
9 | Total Power | 13.2kw |
10 | Rising Angle of Conveyor | 2°~4° |
11 | Speed of Transportation | 72mm/s |
12 | Machine Size ( L x W x H) | (3500*1480*3400)mm |
13 | Speed of Lift (Single Time) | 35s |
14 | Weight of Lift ( Single Time) | 10kg |
15 | Total Weight | 2000kg |
16 |
Hydraulic pressure |
50Kg/cm² |
