Sanitary Ware Smart CNC Robotic Polishing Machine for Faucet

Product Details:
Place of Origin: China
Brand Name: DZ
Certification: CE ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: wooden case packing
Delivery Time: 20days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20sets/per month

Detail Information

Voltage: 380V/50Hz Condition: 100%New
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Field Maintenance And Repair Service,Field Installation Use: Grinding And Polishing
Type: Metal Polishing Machine,Angle Polisher Application: Brass,Steel, Stainless Steel,Aluminum Parts
Warranty: 1 Year Name: Fully Automatic Metal Polishing Machine
High Light:

10.5KW Robot Grinding Machine

,

Bathroom Fittings Robot Grinding Machine

,

380v robotic grinding cell

Product Description

Machine Feature

1- Use Fanuc /ABB/KUKA robot

2- Built-in professional polishing program module

3- Programming mode: teaching device programming, using manual mode to simulate artificial polishing and record track, according to this path automatic operation

4- Full digital control, support multi-program storage and use

5- set various functions and parameters in th display touch panel, convenient operation and fault code display function for troubleshooting and maintenance

6- The polishing range of product is 300mm/3KG
7-fully automatic 360 degree polishing
8-fully automatic loading and unloading
9-multi level sand belt, grinding on demand



II.CHARACTERISTIC

3.1 FUNAC robotic M-20Ia/35M
3.2 Program modular, programming easiness with self-learning system.
3.3 Programming method:demonstrator programming ,with protable handed device, contains manually mode to simulate the workmanship grinding and record the track; automatically operating model is available with pre-settled parameters program.
3.4 Full digital control, the program can be saved and called at any time.
3.5 Rotary sand belt machine and multi - grade sandpaper grinding process can be completed at one time.
3.6 High precision, high efficiency.



III.System composition and main technical parameters


Code Item 20GA 20GB-II 20GB-III 35G-II 35G-III 50G-II 50G-III
1 Robot Cell FUNAC FUNAC FUNAC FUNAC FUNAC FUNAC FUNAC
2 Model 20iA/20 20iA/20 20iA/20 20iA/35 20iA/35 70iA/50 70iA/50
3 Voltage 380V 380V 380V 380V 380V 380V 380V
4 Power 10.5KW 10.5KW 15KW 10.5KW 15KW 16KW 20.5KW
5 Sand Belt Machine Qty. 1 2 3 2 3 2 3
6 Sand Belt Qty. 4 4 6 4 6 4 6
7 Sand belt Dimensions 3000mm 3000mm 3000mm 4000mm 4000mm 4000mm 4000mm
8 Feed Table 1 1 1 1 1 1 1




Sanitary Ware Smart CNC Robotic Polishing Machine for Faucet 0
