Easy Operation Automatic Buffing Machine With 6 Axes DZ Servo System Control
| Brand Name: | DZ |
| Model Number: | NC-64 |
| MOQ: | 1Unit |
| Price: | Negotiable |
| Packaging Details: | wood |
| Payment Terms: | L/C,T/T,Western Union |
Detail Information
Place of Origin:
China(Mainland)
Certification:
CE
Color:
Gray
Warranty:
Surface Polishing Machine
Condition:
New
Application:
Bathroom Industry,Hardware Industry,Tool Industry,Furniture Industry
Usage:
Grinding Polishing Sanitary Ware,hardware Accessories,auto Parts
Voltage:
380V
Delivery Time:
2 weeks
Supply Ability:
30 units/per month
Highlight:
surface polishing machine
,cnc buffing machine
Product Description
Easy Operation Automatic Buffing Machine With 6 Axes DZ Servo System Control
Polishing machine for hardware accessories products including lock panels, door locks, and handles
Key Features
- Advanced 6-axes DZ servo CNC system control with main control screen capture positioning, coordinate digital setting, speed digital setting, software over travel protection, and modular program functions
- Servo motor-driven worm reducer gear system controls polishing unit head and workpiece movement (U, V, W axes) and slide table operation (X, Y, Z axes)
- Four polishing unit heads enable simultaneous processing of four workpieces per cycle with production output of 4 pieces per 30-50 seconds
- Suitable for complex shape handle products, pipe products, and other regular shape products
- Automatic cloth wheel loss compensation system maintains consistent polishing quality throughout production runs
- User-friendly operation with powerful functionality including combined polishing stations and fixtures to eliminate polishing dead angles
- Minimized manual operation with frequency conversion regulation for environmental protection and energy efficiency
Technical Specifications
| Item | Parameter | Remarks |
|---|---|---|
| Size | 4400×3400×2900 mm | Machine Cabinet Size (L×W×H) |
| Power | 33KW | |
| Rated Voltage | 380V 50Hz | |
| Max. Polishing Mop Diameter | 600mm | |
| Min. Polishing Mop Diameter | 400mm | |
| X Axis Travel | 1100 | |
| Y Axis Travel | 900 | |
| Z Axis Travel | 700 | |
| U Axis Travel | ±60° | |
| V Axis Travel | ±360° | |
| W Axis Travel | ±360° |
