China CNC Polishing Machine manufacturer

Mitsubishi Control System CNC Polishing Machine For Bathroom Fitting Accessories

Product Details:
Place of Origin: China
Brand Name: DZ
Certification: CE ISO
Model Number: DK850-8
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Packed in wooden cases to meet the requirements of sea transportation
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 sets/ month

Detail Information

Weight: 6000KG Voltage: 380V/50Hz
Condition: 100%New After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Field Maintenance And Repair Service,Field Installation
Control System: Mitsubishi Warranty: 1 Year
Spindle: 8
High Light:

Mitsubishi Control System CNC Polishing Machine

,

Bathroom Fitting Accessories CNC Polishing Machine

,

Mitsubishi Control System CNC Grinding Machine

Product Description

Peeling Machine For Brass Faucet With 8 heads



1. Main technical parameters of DK850-8 Peeling Machine

Travel X axis 600mm
Y axis 500mm
Z axis 500mm
Distance from Spindle nose to Worktable 90-650mm
Distance from Spindle center to column guide surface 585mm
Worktable Area of worktable 1820*450mm
Maximum load of worktable 500kg
Size of T-shape groove 3-18*130mm



Spindle



Motorized Spindle-8 5.5KW-125-ER32
Speed of main spindle 24000 rpm

Control System

(Mitsubishi)

Configuration Mitsubishi
Motor(Mitsubishi) X axis HG303S-D48
Y axis HG303S-D48
Z axis HG303BS-D48
Sinovo Spindle servo motor-4 Sinovo 11KW
Travel rate Quick travel rate 48000mm/min
Chip feed rate 0~10000mm/min
Accuracy Positional Accuracy JIS±0.005/300
Repeated Positioning Accuracy JIS±0.005/300
Protection cover of machine tool Overall protection
Machine Weight 6000kg
Machine Size 3400*2600*3000mm
